Description
Three phase filter reactor CKSG series three phase series filter reactors are often affected by harmonic current, switching inrush current and operating overvoltage when compensating capacitive reactive power, which will cause capacitor damage and power factor reduction. Install three phase filter reactors to suppress and absorb harmonics, protect capacitors, avoid the effects of harmonic voltage current and impulse voltage current, improve power quality, increase system power factor, and extend capacitor life
Standards:
GB/T 1094.6-2011
GB/T 19212.1-2016
Feature
- Designed with secondary thermal sensitive temperature protection switch
- Full vacuum dipping process, low noise during operation
- Winding frame is reinforced environmental protection flame retardant plastic
Model and Meaning
| CKSG | — | — | -7% | P | K |
| │ | │ | │ | │ | │ | │ |
| 1 | 2 | 3 | 4 | 5 | 6 |
| No. | Name | Meaning |
| 1 | Series code | Dry air-cooled three phase series filter reactor CKDG: single phase |
| 2 | Matching Capacitor rated voltage (kV) | |
| 3 | Rated capacity of matched capacitor (kvar) | |
| 4 | Rated reactance rate XL / Xc (%) | △ :three phase compensation； Y:split phase compensation |
| 5 | P: terminal block | RS485 |
| 6 | K: with temperature protection switch | No mark: without temperature protection switch |
