Description
Service trolleys are produced for complex switchgears with a width of 650, 800, 1000 mm. Purpose and features of the service trolley: – to simplify the necessary work during operation and maintenance of the switchgear; – it’s easy to insert the switch into the switchgear, transport it from place to place to carry out maintenance work; – adjust your height to the height of your cell.
The service trolley consists of:
- base, with wheels attached to it;
- a table where the cassette switch is installed;
- adjustable legs;
- clamps.
Service trolley used for switchgears series KYN28-12 voltage 3 ~ 35 kV
With standard IEC 298.
It is best solution for VCB series MVS1-12 (ZN63), MVS2-12 (ZN63e), MVS3-12 (ZN63M), MVS4-12 (ZN63Me), MVS5-12 (ZN83), MVS6-12 (ZN83e), MVS7-12 (ZN93e).
